FL600~800VA
Flat Design-Office Type German Series
Feature :
- Controlled by a technologically advanced microprocessor guaranteeing high reliability
- Equipped with 2-steps boost & 1-step buck AVR to stabilize output voltage
- Management software is designed to monitor and control UPS status (Optional)
- USB port and cable for managing functions via PC (Optional)
- Coaxial cable line protection (Optional)
- Built-in DC start function enables UPS to be started without AC power supplied
- Constant current, constant voltage battery charger (CCCV Battery Charger)
- No-load shut down function (UPS Green mode)
- UPS will charge itself even though power switch is off (Off mode charging)
- Qver / under voltage protection (UPS will go to battery mode)
- Modem / phone line protection RJ-45 (Optional)
- Lightning / surge protection 175 joules
- UPS will shut down upon battery low ; UPS will restart automatically upon AC recovery (Auto-restart)
- 5VDC USB charger 2.1A max. for charging iPad / iPhone / smart phone (Optional)
Specifications:
| Model | FL-600VA | FL-800VA |
|---|---|---|
| CAPACITY | 600VA/360W | 800VA/480W |
| INPUT | ||
| Voltage | 220/230/240Vac | |
| Voltage Range | -0.05 | |
| Frequency | 50Hz or 60Hz (Auto-Sensing) | |
| OUTPUT | ||
| Voltage Regulation | AC mode / Battery normal:110/115/120Vac or 220/230/240Vac +/- 10% | |
| Frequency | AC mode: 47-53Hz for 50Hz or 57-63Hz for 60Hz ; Battery mode: 50Hz or 60Hz +/- 1Hz | |
| Waveform | Simulated Sinewave | |
| Transfer Time | < 6ms(Typical) | |
| Outlet | German *3pcs with back-up + 3pcs surge only | |
| USB Charger (Optional) | 2 ports 5VDC 2.1A max. | |
| Coax- TV Protector (Optional) | 2 ports | |
| BATTERY | ||
| Voltage | 12VDC | |
| Type | 12V1/7AH *1pc | 12V/9AH *1pc |
| Recharge Time | 5 hours to 90% after complete discharge | |
| Safety Protection | Over Charge & Over Discharge Protection | |
| Advanced Battery Management | Yes | |
| DISPLAY | ||
| LED Status Indicators - 5100CO/ | Blue LED lights continuously: UPS Normal, Blue LED flashing: Back-up | |
| 5700CO Series | ||
| AUDIBLE ALARM | ||
| Battery Mode | Two short tones every 8 seconds | |
| Low Battery | Four short tones every second | |
| Overload | Buzzer: Beeping continuously | |
| Fault | Beeping continuously | |
| MANAGEMENT | ||
| Smart USB (Optional) | Software supporting Windows 95/98/NT/2000/ME/XP/2003/Vista/7/8/10 | |
| ENVIRONMENT | ||
| Operating Temperature | 0° C - 40° C (32 F~104 F) | |
| Humidity | 0-95% (Non-condensing) | |
| Acoustic Noise | <40 dB at 1M | |
| PHYSICAL | ||
| Dimension (W*D*H) | 320 * 175 * 95mm | |
